ehb SMARTdisplay 70


The SMARTdisplay 70 has an intuitive, graphical user interface without additional mechanical controls. The user-friendly interface offers plenty of space for displaying operating parameters. The display with its diverse functions for monitoring, visualisation, display and control of applications with CANbus is the ideal device for customised solutions. Thanks to the very flat design, the high-resolution colour display saves space in the machine.


  • Programmable motor monitoring
  • Simple user programming via ehb Workbench
  • Highly robust housing made of die-cast aluminium
  • Integrated brightness sensor
  • Glare-free, easy-to-clean and acid-resistant surface
  • Capacitive touchscreen/7-inch touch display
Frontabbildung ehb SMARTdisplay 70 mit Spiegelung unten
ehb SMARTdisplay-Ansicht liegend

The ehb SMARTdisplay 70 delivers a multitude of functions for the monitoring, visualisation, operation and control of applications via CAN bus (SAE J1939)

High-resolution colour display with automatic adjustment of background brightness thanks to an integrated brightness sensor
ehb SMARTdisplay 70 ensures perfect legibility even under poor lighting conditions.

Capacitive touch screen
Intuitive, graphic user navigation without additional mechanical operating elements, directly on-screen. UV-resistant, rugged housing from powder-coated aluminium pressure die cast with

high-quality, single-side micro-etched float glass and non-sparkling effect
The slim design of the ehb SMARTdisplay 70 enables perfect integration. The surface will tolerate cleaning with disinfectant. No annoying reflections.

ehb workbench for the configuration of customer-specific visualisation and user interfaces
Individual adaptation of all display and signalling elements and integration of customer-specific logos, symbols and pictograms. Freely positionable and configurable. The Drag&Drop concept enables intuitive operation without programming expertise.

USB port
Transfer of data to USB storage media for postprocessing and documentation. Data and project loading from USB storage media.
Optional customer-specific adaptations.

Real-time operating system and ready for Industry 4.0
Realisation of complex, real-time-capable applications with application reliability in M2M communication.

Web interfaceIndividual display of customer-specific data and application parametrisation via web server. Connection via integrated RJ–45 interface.
Optional customer-specific adaptations.
