ehb SMARTdisplay 835



The SMARTdisplay 835 is specially designed for use on vehicles and off-highway machines. The integrated and freely configurable inputs and outputs make it extremely flexible and save additional I/O modules. The programmability makes it an attractive choice for numerous applications.


  • HMI/programmable motor monitoring
  • Flexible CODESYS user programming
  • Outstanding readability even with high humidity
  • Robust and compact 3.5-inch colour display
  • Outstanding system flexibility thanks to 4 configurable inputs (digital/analogue) and 3 configurable, digital outputs
  • Specially developed for mobile applications
ehb SMARTdisplay 835 - Frontalabbildung - mit Spiegelung unten
Rückseite ehb SMARTdisplay 835- leicht seitlich
ehb SMARTdisplay 835 - seitliche Ansicht

Main features / Key benefits

Rugged HMI/programmable display specifically designed for mobile applications.
Designed to withstand the harshest environments.

3.5" colour screen for harsh environments
Excellent readability even in high humidity conditions

Heated display switches on/off automatically
Excellent for use in low temperatures

Powerful ARM Cortex M7 with 400 MHz clock frequency
Ensures fast response times during operation

512 KB SDRAM and 8 MB flash memory
Enables large amounts of data to be stored and accessed quickly.

4 configurable inputs, digital or analogue
3 configurable digital outputs

Provide excellent system flexibility.

VREF output for external sensors
Stable reference voltage for force sensors and measuring bridges.

CAN interface with J1939 or CANopen
Allows variable communication options.

CAN programming interface
Helpful for easy programming.

Flexible user programming via CODESYS 3.5.
Industry standard programming software.

IP67 protection class
Ensures a high level of protection against dust and water ingress.
