ehb SMARTdisplay 870

ehb5496-1 / ehb5496-2

The SMARTdisplay 870 with large 7-inch display is specially designed for use on vehicles and off-highway machines. The integrated and freely configurable inputs and outputs, Ethernet and CAN ensure maximum flexibility; additional I/O modules are not required. The programmability makes it an attractive choice for numerous applications. The large display area and integrated buttons ensure a high level of operator comfort and a wide range of applications for the user. Optionally, the SMARTdisplay 870 is also available with a touchscreen display (ehb5496-2).


  • Robust HMI/programmable motor monitoring
  • Flexible CODESYS user programming
  • Outstanding readability even with high humidity
  • Large 7-inch colour display with button operation (optional: touchscreen display)
  • Supports mounting in portrait and landscape format
  • Outstanding system flexibility thanks to 4 configurable inputs (digital/analogue) and 4 configurable, digital outputs
  • Flexible communication options through 2 independent CAN interfaces, Ethernet interface and 2 camera inputs
  • Specially developed for mobile applications
Frontabbilung ehb SMARTdisplay 870 horizontal und vertikal

7" Programmable Display
The ehb SMARTdisplay 870 is a 7" programmable display designed for use on vehicles and off-highway machinery.
Designed for use as a stand-alone product, the ehb SMARTdisplay 870 offers the user outstanding flexibility.
The display allows a high level of functionality for a wide variety of application types.
Configuration is done with CODESYS 3.5.

Main features / Key benefits

Optional touchscreen variant
Intuitive operation via touchscreen display.

Option of mounting in landscape or portrait format
Variable use, available mounting space is used optimally.

Robust HMI/programmable display specifically designed for mobile applications
Designed to withstand the harshest environments.

7" colour screen for harsh environments
Provides excellent readability in high humidity environments.

Powerful ARM Cortex A9 processor with 800 MHz clock speed
Ensures fast response times.

512 MB DDR3 SDRAM and 2 GB NAND mass memory
Enables large files to be stored and accessed quickly.

4 configurable inputs, digital or analogue
4 configurable digital outputs

Offer excellent system flexibility

2 independent CAN interfaces, J1939, CANopen and CAN
Allows variable communication options.

Ethernet interface for communication.
Direct connection for demanding communication requirements.

IP67 protection class
Ensures a high level of protection against dust and water ingress.

2 camera inputs
Enables further visual flexibility.

Flexible user programming via CODESYS 3.5.
Industry standard programming software.

Qt programming on request
For added flexibility, the controller can be programmed in Qt language.
