ehb SMARTmodul 04 flex


Compact, robust, secure: The SMARTmodul 04 flex is the small and reliable control module for monitoring and controlling applications via CANbus. Analogue, digital and CANbus signals are securely connected and evaluated. Different sensors, actuators and units can be readily networked. Inputs and outputs can be controlled via CANbus and configured via CAN messages.

Highlights of SMARTmodul 04 flex

  • Compact and robust design
  • Inputs and outputs can be configured via CAN messages
  • Simple networking and implementation of control tasks
  • Control of analogue display instruments
  • Programmable according to customer requirements
SSR StartSperr Relais - Frontabbildung mit Spiegelung
ehb SMARTmodule - Abbildung Lieferumfang

The ehb SMARTmodul 04 flex delivers a multitude of functions for monitoring and controlling applications via CAN bus (SAE J1939).

Analogue, digital and CAN bus signals are reliably interconnected and evaluated
Simple networking of a multitude of sensors, actuators and units.

Inputs and outputs can be controlled via CAN bus
Control tasks are easily achieved via the connected HMI without programming efforts at the controller.

Individually programmable via CAN
The inputs and outputs can be configured via CAN messages.

UV-resistant, rugged PA6 housing for screwed installation Connection via standard plug connectors.
Fast installation and retrofit. Dependable functioning in industrial environments.

No direct access to the sensors installed at the engine
The engine warranty is not affected.

Flexible features
The specific requirement can be programmed flexibly

  • Digital input (pull-up / pull-down)
  • Frequency measurement up to 3kHz
  • Analog input (0-5V / 0-10V / 0-20 mA)
  • Digital output (2A)
  • Temperature validation via Pt100
