ehb SMARTmodul 04 I/O module

ehb5002x

Compact, robust, secure: The SMARTmodul 04 I/O module is the small and reliable module for monitoring and controlling applications via CAN-bus. Analogue, digital and CANbus signals are securely connected and evaluated. Different sensors, actuators and units can be readily networked.
Inputs and outputs can be controlled via CAN-bus. Also possible to adapt the module to the requirements of the respective application beyond the standard components.

Highlights of SMARTmodul 04 I/O module

  • Compact and robust design
  • Configurable for a total of 4 digital inputs and/or outputs
  • Simple networking and implementation of control tasks
  • Control of analogue display instruments
  • Programmable according to customer requirements
SSR StartSperr Relais - Frontabbildung mit Spiegelung
ehb SMARTmodule - Abbildung Lieferumfang

The ehb SMARTmodul 04 delivers a multitude of functions for monitoring and controlling applications via CAN-bus (SAE J1939).

Analogue, digital and CAN-bus signals are reliably interconnected and evaluated
Simple networking of a multitude of sensors, actuators and units.

Inputs and outputs can be controlled via CAN-bus
Control tasks are easily achieved via the connected HMI without programming efforts at the controller

Individually programmable according to customer specification
The standard components can be enhanced by adaptations to the requirement of specific applications.

UV-resistant, rugged PA6 housing for screwed installation.
Connection via standard plug connectors.

Fast installation and retrofit. Dependable functioning in industrial environments.

No direct access to the sensors installed at the motor
The engine warranty is not affected.

Diverse basic variants
Individual requirements can be inexpensively configured

Speed module:

  • Speed adjustment with simple switches and push-butt
  • The programmable working speed can be approached by ramp.
  • Output for analogue speed indication.

Display module:

  • Supports 12V and 24V standard instruments.
  • Engine oil pressure, engine oil and coolant temperature, fuel gauge, speed indicator and much more.
  • An engine change does not require the display panel to be replaced.

I/O module:

  • Configurable for up to four digital inputs and/or outputs.

Sensor module:

  • Transmission of current measured values from four analogue inputs to the CAN-bus
